BOGE S 100-3 Electric Air Compressor (415v)

The latest BOGE S Series outperforms its previous iteration in every way, offering enhanced efficiency, quieter operation, and significantly improved sound pressure levels.

Enquire now

The BOGE S-3 series is deemed essential across various industries, and it’s not hard to see why. Its smartly conceived design allows for easy and secure maintenance – an ergonomic approach that truly adds value. Coupled with top-grade components and meticulous craftsmanship, this series promises both long-lasting durability and unparalleled efficiency.

Download the S-3 series Datasheet PDF »

Advantages

Heat recovery can be integrated
Extremely Quiet
Focus Control 2.0
Maximum Efficiency
Frequency controlled cooling fan

                                Maintenance-friendly design
                                The streamlined design offers easy one-sided access for maintenance through swing-out and removable doors, making upkeep straightforward.


                                Self-contained cooler section with separate fan
                                Due to the strategically designed cooling air duct, the system fully utilises 100% of the fan's output. This effective cooling remains operational even when the system is open, proving invaluable during maintenance and test runs.


                                Internal steel pipework
                                In contrast to the often-used hose connections that require frequent replacement, steel pipes offer long-lasting durability and effectively minimise leaks over extended periods.


                                Safety oil separator system
                                In a well-engineered system, a horizontal receiver works seamlessly with a precision-crafted preseparator to efficiently divide the air/oil mixture. While the oil is retained within the compressor circuit, the purified air is directed to the end-user.


                                Intake filter with paper micro filter insert
                                The integrated preseparator prevents dust and dirt from entering the compressor circuit in the first place, thereby extending not only the service life of the airend but also that of the filter element itself.


                                Valveless oil circuit with multifunctional suction regulator
                                Featuring energy-saving low power consumption during idle periods, a fully balanced start-up to preserve the entire drive system, and an automatic shutdown mechanism in case of faults, this design epitomises operational safety.


Delivery Volume (FAD) 336.5cfm - 434cfm
Delivery Pressure (8 bar) 115 psig
Delivery Pressure (10 bar) 150 psig
Delivery Pressure (13 bar) 190 psig
Installed Motor Power (75kW) 100hp
